汽車MOS 通用MOS

Model No. 型號	Package Type 封裝形式	Config ration 配置比例	MOSFET Type MOS類型	VDS(V) DS耐壓	VGS(V) GS耐壓	Vth(V) Vth(V)	RDS(ON)(mΩ)max. at VGS= RDS(ON)(mΩ)max. at VGS=		ID(A) ID(A)
Model No. 型號	Package Type 封裝形式	Config ration 配置比例	MOSFET Type MOS類型	VDS(V) DS耐壓	VGS(V) GS耐壓	Vth(V) Vth(V)	10V	4.5V	Tc=25℃	TC=100℃
AP2312-AU	SOT-23	Single	N	20	±12	0.3-1.0	-	13.5/18	6.8	4.4
AP30H100KA-AU	TO-252	Single	N	30	±20	1-2.5	3.6/4.2	5/7	100	54
AP30P06G-AU	PDFN5X6	Single	P	-30	±20	1-2.5	24/29	30.4/39	26	18
AP30P06K-AU	TO-252	Single	P	-30	±20	1-2.5	24/29	30.4/39	36	25.5
AP5040-AU	SOT-23	Single	N	40	±20	1-2.2	30/40	40/60	5	3
AP50N04QD-AU	PDFN3X3-D	Dual	N	40	±20	1-2.5	13/15	17/20	20	14
AP50N04GD-AU	PDFN5X6-D	Dual	N	40	±20	1-2.5	13/15	17/20	30	20
AP85N04G-AU	PDFN5X6	Single	N	40	±20	1-2.2	5.0/5.9	7.5/10	65	41
AP85N04K-AU	TO-252	Single	N	40	±20	1-2.2	5.0/5.9	7.5/10	65	41
AP120N04K-AU	TO-252	Single	N	40	±20	1-2.5	3.3/4.2	5.4/7.5	120	78
AP200N04D-AU	TO-263	Single	N	40	±20	1.0-2.2	2.4/2.8	3.2/4.0	160	112
AP15P04Q-AU	PDFN3X3	Single	P	-40	±20	1-2.2	27/33	34/42	15	10.5
AP40P04K-AU	TO-252	Single	P	-40	±20	1-2.2	10/13	15/22	40	26
AP40P04G-AU	PDFN5X6	Single	P	-40	±20	1-2.5	10/13	15/22	40	26
AP80P04K-AU	TO-252	Single	P	-40	±20	1-2.5	5.8/7	7.5/9	80	50
AP85P04G-AU	PDFN5X6	Single	P	-40	±20	1-2.5	4.3/5.3	5.9/7.6	85	60
AP100P04K-AU	TO-252	Single	P	-40	±20	1-2.5	4.6/6.0	6.5/8.3	100	70
AP110P04D-AU	TO-263	Single	P	-40	±20	1-2.5	4.5/5.5	6.1/7.8	110	75
AP2K260-AU	SOT-23	Single	N	60	±20	1-2.5	1800/2200	2200/2600	0.3	0.2
AP8060-AU	SOT-23	Single	N	60	±20	1.2-2.5	55/80	75/90	3	2.3
AP6009S-AU	SOP-8	Single	N	60	±20	1-2.2	14/18	17/21	9	7
AP6026Q-AU	PDFN3X3	Single	N	60	±20	1-3	26/35	-	25	17
AP25N06Q-AU	PDFN3X3	Single	N	60	±20	1-3	26/35	-	25	17
AP68N06Q-AU	PDFN3X3	Single	N	60	±20	1-2.2	13.2/16	15.2/20	40	28
AP68N06G-AU	PDFN5X6	Single	N	60	±20	1-2.2	13.2/16	15.2/20	50	33
AP25N06K-AU	TO-252	Single	N	60	±20	1-3	26/35	-	25	17
AP25P06Q-AU	PDFN3X3	Single	P	-60	±20	1-2	50/60	60/72	25	19
AP25P06G-AU	PDFN5X6	Single	P	-60	±20	1-2	52/60	64/72	25	19
AP25P06K-AU	TO-252	Single	P	-60	±20	1-2	52/60	64/80	25	19
APG068N04Q-AU	PDFN3X3	Single	N	40	±20	1-2	5.7/6.8	8.5/11	54	34
APG068N04GD-AU	PDFN5X6-D	Dual	N+N	40	±20	1-2.0	6.7/7.8	9.5/12	45	32
APG058N04GH-AU	PDFN5X6	Single	N	40	±20	2-4	4.8/5.8		40	40
APG033N04GH-AU	PDFN5X6	Single	N	40	±20	2-4	2.8/3.3		120	74
APG032N04G-AU	PDFN5X6	Single	N	40	±20	1.2-2.2	2.7/3.2	3.8/4.6	100	62
APG025N04GH-AU	PDFN5X6	Single	N	40	±20	2-4	2.0/2.5		150	100
APG015N04GH-AU	PDFN5X6	Single	N	40	±20	2-4	1.2/1.5		130	82
APG015N04KH-AU	TO-252	Single	N	40	±20	2-4	1.2/1.5		130	82
APG024N04G-AU	PDFN5X6	Single	N	40	±20	1.2-2.2	2.0/2.4	3.0-3.6	120	74
APG4015G-AU	PDFN5X6	Single	N	40	±20	1-2.5	1.6/1.8	2.0/3.3	150	100
APG013N04G-AU	PDFN5X6	Single	N	40	±20	1-2.0	1.1/1.3	1.6/1.8	160	100
APG130N06Q-AU	PDFN3X3	Single	N	60	±20	1.2-2.2	10.5/13	13.5/16	45	29
APG022N06G-AU	PDFN5X6	Single	N	60	±20	1-2.5	1.9/2.3	3.0/3.5	150	100
APG072N06G-AU	PDFN5X6	Single	N	60	±20	1-3	5.3/7	7.6/10	45	30
APG145N06GD-AU	PDFN5X6-D	Dual	N+N	60	±20	1.2-2.2	11.5/14.5	14.5/17.5	40	27
APG080N06GD-AU	PDFN5X6-D	Dual	N+N	60	±20	1-2.5	6.6/8	8.4/10	62	42
APG180N01GD-AU	PDFN5X6-D	Dual	N+N	100	±20	1-2.5	15/18	20/24	25	17
APG250N01G-AU	PDFN5X6	Single	N	100	±20	1.2-2.8	18-25	25-38	40	25
APG250N01K-AU	TO-252	Single	N	100	±20	1.2-2.8	18-25	25-38	40	25
APG250N01D-AU	TO-263	Single	N	100	±20	1.2-2.8	18-25	25-38	40	25
AP3205D-AU	TO-263	Single	N	55	±20	2-4	7/10	-	110	70
